50mm/100mm LCD Low-Intensity Portable X-Ray Imaging Scope
50mm/100mm LCD Low-Intensity Portable X-Ray Imaging Scope
50mm/100mm LCD Low-Intensity Portable X-Ray Imaging Scope
50mm/100mm LCD Low-Intensity Portable X-Ray Imaging Scope
50mm/100mm LCD Low-Intensity Portable X-Ray Imaging Scope
50mm/100mm LCD Low-Intensity Portable X-Ray Imaging Scope

50mm/100mm LCD Low-Intensity Portable X-Ray Imaging Scope

Model NO.:
MCL-50/100
Price:
USD 3000.00-3000.00
Delivery:
FOB
Minimum order quantity:
1
  • Place of Origin:CN;GUA
  • Instrument classification:Class II
  • Brand Name:Mecan
  • Model Number:MCL-50/100

LCD Low-Intensity Portable X-Ray Imaging Scope

MCL-50/100

Product Description

What is the detail of our LCD Low-Intensity Portable X-Ray Imaging Scope?

The 50mm/100mm LCD Portable X-Ray Unit is a high frequency X-Ray Imaging Scope which is based on CCD sensors imaging princle. Model is a unique device combining radioscopy and radiography functions. It is equipped with small display transmitting images to the computer, which by means of simple software can be recorded to digital media or printed out. The unit is indispensable in traumatology and orthopaedics for emergency diagnostics. 50mm LCD Portable X-Ray Unit is widely used in the radioscopy for knee joint, ankle ,femoral shaft and other thick parts.

Order number

50

100

Output Image size

50 mm

100*75mm

Survey Thinkness

300 mm

300mm

X-ray tube voltage

45-70KV

45-90KV

X-ray tube voltage deviation

≤10%

≤10%

Tube current

0.25-0.5mA

0.25-0.5mA

Tube current deviation

≤20%

≤20%

Resolution

≥3lp/mm

≥3lp/mm

Generator working frequency

20Khz

20Khz

Stand-Position Protection Area

≤0.33mGy/h

≤0.33mGy/h

Weight

≤3.6KG

≤4.5KG

Power Consumption

≤200W

≤200W

Power Supply

AC220V±10%

AC220V±10%
