AutoSight900 Vision Screener
AutoSight900 Vision Screener
AutoSight900 Vision Screener
AutoSight900 Vision Screener

AutoSight900 Vision Screener

Model NO.:
MCE-900
Price:
USD 1888.00-3666.00 / unit
Delivery:
FOB
Minimum order quantity:
1 unit
Supply Ability:
1000 unit / Month
Country of Origin:
Guangzhou, Shenzhen, etc.
Stock Time:
3-15 working days Days
  • Model Number:MCE-900
  • Brand Name:Mecan

AutoSight900 Vision Screener







Product introduction

Auto sight 900 is a portable vision screener, which uses the principle of Shack - Hartmann wave-front sensor to measure diopter, including concave-sphere, astigmatism and axial view, etc..- .jpg

1 dimension:200mm×80mm×270mm

2The product is classified according to safety, the charger is type I, the host is the internal power.

3The product is a kind of laser equipment, meeting the standard of EN60825-1 (1996) IEC825-1 (1996), with a wavelength of 850nm and a laser power of less than 250uw

4 Data reading time: test an average of 5-9 readings per eye for 2.5 seconds

5 Battery life: lasts more than 5 hours

6 Low battery alarm: it can show use time, power display and sound alarm

7 Infrared printing interface: infrared connection with thermal printer

8 Data transmission interface: use common micro USB interface, ordinary, android phone cable can be connected to desktop computers, notebook computers, mobile phones, tablets,used for software upgrade or transform data into electronic medical records.

9 Data storage capacity: 420 binocular storageresults.



The performance parameters



  parameter

Scope of measurement

step

Tolerance

Range of diopter(S)

Myopia

-9.00D  ~ +2.50D

0.25D

±0.50D or±20%

Normal

-6.00D  ~ +8.00D

Infant model

-6.00D  ~ +8.00D

Range of cylinder(C)

-3.00D~0.00D

0.25D

±0.50Dor±20%

axial (A)

1°~180°

1°

±5°


1:doctor observation      2:detecting window    3:distance sensor part                    4:press key

       5:Infrared emitter (reserved)           6:Charger socket                     7:screen                                 8:base





measurement QQ20180717160935.jpg
