1.Open and Close breathing circuit by a switch easy and fast.
2.Easy install CO2 absorbing canister, convenient for Sodalime exchange and canister cleansing.
3.Exclusive design for overall breathing circuit leakage test which is also for saving the circuit from contaminated after surgery.
4.Highly integrated breathing circuit anti leakage,lessen negative effects caused by circuit resistance and compliance securing a steady gas glow and accurate tidal volume output
5.Precise airway pressure control system,the adjust range is from(0-50cmH2O)which is easy to adjust manuaiiy
6.0-90 degree adjustable rebreathing bag connector which is cater to doctor habits.
7.Pressure regulating devices at gas inlets port assuring gas flow to vaporizer steady.
8.Highly precise vaporizer with high technology to assure the accurate pressure flow and temperature compensation. made in imported materia
9.International standard gas inlet device filters dust over 75um
10.Reusable anesthesia gas absorber for clean surgery room environment
Main technical parameters
Applicability:1kg to 100kg
Operation mode:Closed, Semi-closed, and open breathing circuit for option.
Flow range: 0.1-4.0L/min
Ventilation modes: Autonomous breathing ,Controlled manually
Autonomous breathing: According to the strength of the animal s spontaneous respiration
Controlled manually: 10ml—2000ml
Rate:Autonomous breathing: according to the animal s spontaneous breathing frequency
Controlled manually: according to the frequency of anesthetist operation
IE: Autonomous breathing: According to the breathing rate of the animals
Controlled manually: According to the breathing ratio of the anesthesiologist's operation
With CO2 absorber, circulatory anesthesia is available
Anesthetic gas absorber is optional and can ensure clean air in the operating room and laboratory room
