Portable Veterinary Ultrasound Diagnostic Machine
- Model NO.:
- MCU-7000A
- Price:
- USD 2199.00-4999.00 / piece
- Delivery:
- FOB
- Minimum order quantity:
- 1 piece
- Supply Ability:
- 1000 piece / Month
- Country of Origin:
- Guangzhou,Shengzhen,Shanghai,etc
- Type:Doppler Ultrasound Equipment
- Place of Origin:CN;GUA
- Instrument classification:Class II
- Brand Name:MeCan
- Model Number:MCU-7000A
Portable Veterinary Ultrasound Diagnostic Machine
MCU-7000A
What is feature of our Portable Veterinary Ultrasound Machine?
The MCU-7000A veterinary ultrasound machine is used in livestock farms and animal clinics. The 3.5MHz probe is suitable for pigs, sheep and dogs; the 6.5MHz probe is suitable for cattle and horses.
MCU-7000A Veterinary Ultrasound Machine Parameters | |||
Probe | 7.5 MHz Linear Rectal Probe | 3.5 MHz Convex Probe | |
Scan depth (mm) | ≥80 | ≥140 | |
Resolution (mm) | Lateral | ≤1( depth ≤60) | ≤3( depth ≤80) |
Axial | ≤1( depth ≤80) | ≤1( depth ≤80) | |
Blind area (mm) | ≤3 | ≤6 | |
Geometric Position | Horizontal | ≤5 | ≤7.5 |
Vertical | ≤5 | ≤5 | |
Monitor Size | 5.6inch TFT-LCD | ||
Display modes | B | ||
Gray scales | 256 | ||
Image permanent storage | 64 frames | ||
Scanning depth | 70mm-240mm | ||
Image process | Faked color, gray calibration image smooth and histogram | ||
Frame correlation adjust | 3 | ||
Focuses | Focuses location move | ||
Image process | Gray calibration,image smooth and histogram | ||
Continuous working hours | ≥3 hours | ||
Measuring functions | Distance, circumference, area, volume, EF rate | ||
