Veterinary Portable Ultrasonic Diagnostic Devices
- Model NO.:
- MCU-3000
- Price:
- USD 1000.00-2999.00 / piece
- Delivery:
- FOB
- Minimum order quantity:
- 1 piece
- Supply Ability:
- 1000 piece / Month
- Country of Origin:
- Guangzhou,Shengzhen,Shanghai,etc
- Type:Doppler Ultrasound Equipment
- Place of Origin:CN;GUA
- Instrument classification:Class II
- Brand Name:MeCan
- Model Number:MCU-3000
Veterinary Portable Ultrasonic Diagnostic Devices
MCU-3000
What is feature of our Veterinary Portable Ultrasonic Machine?
The MCU-3000 veterinary ultrasound machine is used in livestock farms and animal clinics. The 3.5MHz probe is suitable for pigs, sheep and dogs; the 6.5MHz probe is suitable for cattle and horses.
MCU-3000 Veterinary Ultrasound Machine Parameters | |||
Probe | 6.5 MHz Linear Rectal Probe | 3.5 MHz Convex Probe | |
Scan depth (mm) | ≥80 | ≥140 | |
Resolution (mm) | Lateral | ≤1(depth≤60) | ≤3(depth≤80) |
Axial | ≤1(depth≤80) | ≤1(depth≤80) | |
Blind area (mm) | ≤3 | ≤6 | |
Geometric Position | Horizontal | ≤5 | ≤7.5 |
Vertical | ≤5 | ≤5 | |
Monitor Size | 5.6 inch TFT-LCD | ||
Display modes | B,B+B,B+M,M,4B | ||
Gray scales | 256 | ||
Image permanent storage | 64 frames | ||
Scanning depth | 90mm-240mm | ||
Frame correlation adjust | 3 | ||
Focuses | Focuses location move | ||
Image process | Gray calibration,image smooth and histogram | ||
Continuous working hours | ≥3.5 hours | ||
Measuring functions | Distance, circumference, area, volume, EF rate | ||
