25kW Txawb FPD C-arm System

Qauv: MCI0031

Professional-Qib Mobile C-arm System rau Interventional & Orthopedic Cov txheej txheem

Lub 25kW Txawb FPD C-arm System muab qhov tshwj xeeb imaging kev ua tau zoo los ntawm nws 30 × 30cm ca vaj huam sib luag ntes (FPD) thiab 25kW high-frequency generator, ua rau nws zoo tagnrho rau vascular, orthopedic, thiab interventional phais.

Cov yam ntxwv tseem ceeb ntawm Peb Lub C-arm System

1. Kev ua tau zoo FPD imaging

• 30 × 30cm Flat Vaj Huam Sib Luag Detector: distortion-dawb duab

• 77% DQE (Detective Quantum Efficiency): Superior teeb liab-rau- suab nrov piv rau cov ntaub so ntswg muag pom

• 3.2LP/mm Resolution: Captures zoo anatomical cov ntsiab lus tseem ceeb rau tus txha caj qaum thiab vascular cov txheej txheem

2. Hwj chim 25kW Generator

• 60kHz High-Frequency Inverter: Cov zis ruaj khov rau cov neeg mob rog rog thiab cov duab ntom ntom

• 1000kJ Tube Peev Xwm: Txhawb nqa ntev fluoroscopy thaum muaj kev cuam tshuam nyuaj

• Pulse Fluoroscopy (0.3-100mA): Ntsuas cov duab zoo nrog kev txo koob tshuaj

Kev siv tshuaj kho mob ntawm FPD C-arm System

• Vascular Interventions: DSA rau embolizations thiab stent placements

• Orthopedic Surgery: Real-time taw qhia rau cov leeg txha caj qaum thiab txo pob txha

• Tumor Ablation: Precision imaging rau TACE thiab RF cov txheej txheem
