China Operation Equipment Syringe Pump manufacturers-MeCan Medical

MeCan Medical China Operation Equipment Syringe Pump manufacturers-MeCan Medical,MeCan provide one-stop solutions for new hospitals,clinics,labs and universities,has helped 270 hospitals,540 clinics,190 vet clinics to set up in Malaysia,Africa,Europe,etc.we can save your time,energy and money.




Quantity:
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button

Main features

Colorful TFT screen with keyboard button

Automatic self-identification of 5mL, 10mL, 20mL, 30mL and 50mL syringes

Compatible with all kinds of syringe brands

4 injection modes: ml/h Mode. Weight Mode, Volume-Time Mode, Standby Mode

25 injection speed units

KVO & Bolus function

Visible and audible Alarms

Real time display

Rechargeable Lithium battery can work continuously for over 4.5 hours

Stackable combination with single AC power supply

Double CPU

Autosave 2000 syringe records


Technical Parameters

Applicable Syringe Specification

5ml, 10m1, 20ml, 30ml, 50ml

Syringe Brand

Any syringe brand

Scope of Injection rate

0.1-100mI/h, 5mI Syringe

0.1-600ml/h, 20ml Syringe

0.1-800ml/h, 30ml Syringe

0.1-1200ml/h, 50ml Syringe

Bolus rate

50-100ml/h(Default 50ml/h), 10ml Syringe

50-300ml/h(Default 50ml/h), 10ml Syringe

50-600ml/h(Default 50ml/h), 10ml Syringe

50-800ml/h(Default 50ml/h), 10ml Syringe

50-1200ml/h(Default 50ml/h), 10ml Syringe

KVO rate

0.1-1.0ml/h, adjustable at Increment level of 0.01ml/h

Accuracy

±2%

Speed unit (Dose-rate unit)

25kinds of injection-speed units as follows:

ml/h, mg/min. m9/h, mg/24

mg/kg/min. mg/kg/h.

mg/kg/24h. ug/min. ug/h,

Ug/24h, ug/kg/min. ug/kg/h,

ug/kg/24h, U/min, U/h, U/24h.

U/kg/min, U/kg/h. U/kg/24h,

kU/min, kU/h, kU/24h,

kU/kg/min, kU/kg/h,

kU/kg/24h

Accumulated Injection Volume

0.0001-999999ml

VTBI

0.1-1000ml

Injection

Three levels for selection:

Pressure

(L)300mm/Hg(M)500mm/Hg(H)1100mm/Hg

Injection

4modes: ml/h mode, Weight mode,

Mode

Volume-Time mode

Alarm

AC power failure, Syringe falls off, Reinstall

syringe, Countdown, Air, Occlusion, Low

battery, Error, Over, no enough drugs,

beyond Parameters range

Operating Condition

Environment Temperature: 5-40

Power

Relative Humidity: 20%-90%

Atmospheric Pressure: 700 hPa-1060hPa

AC 100V-240V, 50Hz/60Hz,

DC 14.8V(+5%,-10%) 2000mAh rechargeable

Input Power

25VA

Battery

Rechargeable battery; Charging time: 12-16h;

Discharge time: over 4.5h(when the battery is full)

Fuse

AC 250V 3.15A

Safety Level

Class 1, Type BF

IP Grade

IPX4

Dimension

245mm x 135mm x 120mm

Weight

G.W:3.3kg, N.W: 2.3kg


MeCan Medical  is finely designed. Its design is finished by considering many factors such as frame construction, control system design, mechanism design, and operating temperatures.
