MeCan Medical Customized -86 Degree Lab Deep Refrigerator Chest Ultra Low Temp Laboratory Freezer manufacturers From China,More than 20000 customers choose MeCan. Every equipments from MeCan gets passed strict quality inspection,and final passed yield is over 99.9%.
Quantity: | |
---|---|
Place of Origin:CN;GUA
Instrument classification:Class II
Brand Name:MeCan
Model Number:MCF-DW-HW138/328/400/438/668
Model: MCF-DW-HW138/328/400/438/668
Specs list of the -86 Degree Chest Ultra Low Temp Laboratory Freezer:
Model | Capacity | External size (WxDxH) mm | Inside size (WxDxH) mm | Input power | Weight (N.W. / G.W. |
MCF-DW-HW138 | 138 liters | 890x1320x1009 | 470*570*490 | 800W | 230/250KG |
MCF-DW-HW328 | 328 liters | 890x2005x1009 | 470*1200*582 | 1500W | 300/320KG |
MCF-DW-HW400 | 400 liters | 890x2005x1009 | 470*1200*582 | 1500W | 300/320KG |
MCF-DW-HW438 | 438 liters | 890x2005x1009 | 540*1270*590 | 1500W | 320/340KG |
MCF-DW-HW668 | 668 liters | 1150x2050x1009 | 815*1200*660 | 2500W | 340/360KG |
Control System of the -86 Degree Chest Ultra Low Temp Laboratory Freezer:
Microprocessor-based temperature control system,inside temperature ranging from -10℃~-86℃
Can be set freely, controlling precision is 1℃.Digital temperature display.
Keyboard lock and password protected configuration page, Delayed start and safe stop interval between restart and being terminated.
Audible and visual alarm: High or low temperature alarm, Power failure alarm, Low battery alarm, Door ajar alarm, Filter blocking alarm, system failure alarm.
With temperature printer, record 7days data. 72 hour battery back up for printer and controller display.
Power supply: 220V /50Hz 1 phase, can change as 220V 60HZ or 110V 50HZ or 110V 60HZ
Structure Design of the -86 Degree Chest Ultra Low Temp Laboratory Freezer:
Chest type, Stainless steel interior, Outer is painted steel panel, 4units Casters for easy handing
Rotatable assistant door handle, top door with key lock.
Two times foaming technology, double seal design. 155mm extra thickness heat insulation.
Optional: chart recorder, CO2 back up, storage racks, boxes, remote alarm system.
Refrigerator System of the -86 Degree Chest Ultra Low Temp Laboratory Freezer:
Unique refrigeration circulation and unipolar compressor oil-lubricated technology.
China patient technology of mixture refrigeration, which composed of R134a, R404a, R23, R24, N2, R600a and more, CFC free.
