The use of places: operating rooms, wards, outpatient clinics, can be used
1. High performance
2. Quick and easy to use, accurate measurement
• Using contactless pyroelectric infrared technology to get the ear temperature, the measurement time is only needed 2 to 3 seconds; effectively prevents the risk of cross infection
• Built-in Bluetooth module for TEMP function, patient's temperature data is
quickly transferred to MCS1503 by Bluetooth as well as the figure is displayed on
screen, convenient to measure different patient, it shorten the time and cuts
the clinical application cost
• Rapid NIBP measurement technology, it shorten the measuring time to 20~30
seconds from former 60~120 seconds, provides PR figure display
• Quickly switches the relative parameters for different type of patient such
as adult, child and neonate
• Optional Masimo SpO: with PI(perfusion index) figure display, PI provides
caregiver with an indication of the reliability of SpO: measurement
3. Smart and lightweight,sturdy and durable
• 6 inch LED back-light LCD display provides a clear and distinct view
•The net weight is 1.25kg, small enough and light enough to ward round monitoring
• Wall mount and trolley movement solutions
• Precision and hermitic design, it is able to withstand 1.2 meters'drop test
• Liquid protection grade gets to IPX1, effectively prevents the damage by liquid
4. To meet clinical need, excellent vital signs monitor
• 50 groups of NIBP data storage, easy to review
• Super li-on battery provides more than 12 hours of cautious monitoring
• Various accessories of NIBP and SpO: meet the need of different patients including adult, child and neonate
| Standard Configuration: |
COMEN SpO2, NIBP, PR |
Optional Configuration: |
Nellcor/Masimo SpO2, Ear Temp, Suntech NIBP |
Safety Standards |
ISO 13485:2003 approved, CE marking according to MDD93/42/EEC |
Physical Characteristics |
Product Size: | 130mm*125 mm*219mm |
Net Weight: | 1.25kg (battery excluded) |
Screen: | 6"LED screen |
Battery Type: | Rechargeable Lithium-ion battery |
Battery Capacity: | 2200mAh |
Battery Recharging Time: | Maximum 5.5 hours for charging; |
Battery backup: | 12 hours for standby mode |
Operation Environment |
working Temp: | 5-40°C |
Humidity: | ≤93% |
Power Supply: | 100-240V~, 50/60Hz±1Hz |
| Indicator | Power indicator |
Battery indicator |
QRS beep |
Operating key sound |
| Interface | RS-232 interface |
AC power input |
Data storage |
Patient data Review: | 50 groups |
Power-off storage: | Yes |
Features |
Patient type: | Adult, Pediatric |
Mode: | Parameter Setting Mode, Review Mode, Standby Mode, Maintenance Mode |
| Data: | Date storage, review and transfer |
| NIBP |
Method: | Automatic oscillometric |
Work mode: | Manual / Automatic |
Measurement Unit: | mmHg / Kpa selectable |
Measurement types: | Systolic, Diastolic, Mean |
Range of systolic pressure: | Adult Mode:40-270mmHg
Pediatric Mode:40-200mmHg |
Range of diastolic pressure: | Adult Mode:10-215mmHg
Pediatric Mode:10-150mmHg |
Range of meanpressure: | Adult Mode:20-235mmHg
Pediatric Mode:20-165mmHg |
Over-pressure protection: | Both Hardware and software over pressure protection |
Accuracy: | ±3mmHg |
Resolution： | 1mmHg |
| PR from NIBP: | 40-240bpm |
| Resolution: | 1bpm |
Accuracy:
| ±3% or ±3bpm, whichever is greater |
Masimo SpO2 |
Measurement range: | 1~100% |
Resolution: | 1% |
Accuracy: | ±2% (70-100%, Adu/Ped, non-motion)
±3% (70-100%, motion)
Unspecified (1-69%) |
| PR measurement: |
|
| Range: | 25~240bpm |
Resolution: | 1bpm |
Accuracy: | ±3bpm(non-motion) ±5bpm(motion) |
| PI value: | 0.02~20 |
| Resolution: | 0.01% (0.02%～9.99%) 0.1% (10.0%～20.0%) |
Accuracy:
| Unspecified
|
Comen SpO2 |
Measurement range: | 0~100% |
Resolution: | 1% |
Accuracy: | ±2% (70~100%, Adu/Ped, non-motion) Unspecified (1-69%) |
| PR measurement |
|
| Range: | 20-254bpm |
| Resolution: | 1bpm |
| Accuracy: | ±2bpm |
PI value:
| 0.05~20 % |
Temperature (Ear Probe) |
Range: | 34.0°C~42.2°C |
TEMP sensor: | IR Ear Temperature probe |
Resolution: | 0.1°C |
Accuracy: | ±0.2°C |
