Dynamic FPD Digital Radiography and Fluoroscopy System

Model：MCI0041

Overview

Designed for gastrointestinal, orthopedic, and angiographic applications, this DRF System combines a 434mm dynamic FPD with advanced fluoroscopy capabilities to deliver unparalleled clarity and efficiency.

Key Features of DRF System

1.Superior Imaging with Dynamic FPD Technology

• 434mm large-area dynamic FPD ensures high-resolution imaging for complex procedures.

• 3072×3072 prime matrix and 139µm pixel spacing capture minute anatomical details.

• Supports continuous fluoroscopy (up to 30fps) and pulse fluoroscopy (up to 22fps) for real-time diagnostics.

2. Versatile Radiography & Fluoroscopy Modes

• Radiography and Fluoroscopy System with 40–150kV tube voltage and 10–800mA current for flexible exposure control.

• Serial radiography at 3fps (3072×3072) and 6fps (1536×1536) is ideal for dynamic studies.

3. Optimized Workflow Integration

• DRA80 workstation offers 16-bit A/D conversion and ≥3.7lp/mm spatial resolution

4. Robust Hardware Configuration

• High-voltage generator (65.5kW max output) and Canon E7252X X-ray tube

• Collimator with ≥1mmAL filtration and LED beam

Applications

The Dynamic FPD System excels in:

• Gastrointestinal studies (e.g., barium swallows).

• Orthopedic imaging (joint and spine assessments).

• Angiographic procedures with real-time fluoroscopy.
