Far Infrared Massage Bed - Lumbar Vertebra Traction

MeCan Medical China MCT-ALC-3 Far Infrared Massage bed/Lumbar Vertebra Traction Bed manufacturers - MeCan Medical,MeCan provide one-stop solutions for new hospitals,clinics,labs and universities,has helped 270 hospitals,540 clinics,190 vet clinics to set up in Malaysia,Africa,Europe,etc.we can save your time,energy and money.


facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button
  • Place of Origin:CN;GUA

  • Brand Name:MeCan

  • Model Number:MCT-ALC-3

Far Infrared Massage bed/Lumbar Vertebra Traction Bed



Specifications of lumbar vertebra traction bed

1. It can carry out systematic massage or partial massage
2. It has far infrared thermal therapy function.

Massage technological parameters:

1. Distance of motor-driven device: ≥800mm.

2. Rolling massage scope (L×W): ≥1600mm×380mm.

3. Rolling massage period: 40s±5s.


Rolling massage timing:

1. Timing scope: 1min~60min (Adjustable).       Timing step: 1min.

2. Timing error: ±5%.


Vibratory massage:

1. Vibratory massage scope (L×W): ≥800×200mm.

2. Vibration load: the bed will not stop vibrating when being evenly loaded 135Kg.

3 Vibration frequency : 50Hz±3Hz.


Thermal therapy technological parameters:

1. Range of temperature control: 30°C~48°C.

2. Temperature control error: -5°C~+8°C.

3. Heating-up time: it needs less than 20 min to reach 23°C~25°C.

4. Temperature homogeneity: the temperature homogeneity is less than 6°C in the range of 1600mm×380mm.

5. Overtemperature alarm: when the central point of the bed reaches 48°C±3°C, the machine shall cut off the powers of heating device and massage and stop working. An alarm will be given in 1~20s.

6. Total noise of the device shall be no more than 65dB (A).


Traction technological parameters:

1. Input voltage: 220V.

2. Input power: 80W.

3. Distance of traction: 200mm.

4. Control mode: click.


Technological advantages:

It has separate far-infrared massage function:

1. It can carry out systematic massage or partial massage (e. g. upper body, neck, waist, and lower body).

2. It has vibration massage function.

3. It has far infrared thermal therapy function.

It has separate lumbar vertebra traction function:

   It is electrically controlled with an inching switch. Both the doctor and the patient can control the value of traction force. A hand switch can help you achieve artificial automatic intermittent traction, continuous traction, repetitive traction and automatic traction force compensation. The traction force shall be endurable to the patient. The motive power is straight extendable conveyor belt and the apparatus has electronic display for traction force and touch key.



1. Prolapse of lumbar intervertebral disc, hyperosteogeny, cervical vertebra disease.

2. Stubborn pains of shoulder, waist, and leg, sciatica.

3. Acute or chronic lumbar muscle strain, lumbar degenerative diseases.

4. Waist, back, leg muscles and soft tissue sprain and bruise.

5. Fatigue syndrome from strenuous work.

6. It can improve sleeping and get rid of or guard against weariness.

7. It can dredge the whole body’s meridian and help to prolong life.

8. It promotes recovery of sequelae of apoplexy.



One Stop Supplier
Our Advantage

1. One stop supplier for medical equipments and laboratory equipments in Guangzhou
2. More than 2000 hospitals have become our partners
3. Superior quality with factory price
4. Quick reply and considerate service
5. CE,ISO,FDA Certificate
6. Fast delivery by air, sea or in other ways
7. More than 10 years in medical machines supply business
8. Exported to more than 109 countries
9. Warranty time: AT LEAST 12 months and Over 8 years' technical and accessories-change support
10.Excellent and immediate after-sale service



1. From the Biomedical Engineer of Senegal.

hello, the installation of the RX unit was a success. all is ok and i have a very good picture.



2. From Dr. Salman Hasan, Doctor from Nigeria

Hello we have installed the radio and we are really satisfied with its operation.


3. From Dr. Emma Adapoe, Ghana, Africa.

 Mecan Medical Company Limited:

I have tried them for their honesty

I have tested their products for Good Quality

I have experienced their Good and and nice service and customer relations

I endorse Mecan because they stand the test of time.



Please contact us for the MCT-ALC-3 Far Infrared Massage bed/Lumbar Vertebra Traction Bed
