Multi-channel Syringe Pump
Features and Functions:
* Double-channel(multi-channel), sub-rate injection.
* Four kinds of injection modes: Rate mode, Time mode, Body Weight mode,Link mode.
* Innovative design of outer appearance gives a strong sense of science and technology.
* Double CPU makes the process of injection safer and more reliable.
* The use of TFT color LCD makes the screen display more remarkable.
* Digital menu, easy operation; functions fully meet the clinical demand.
* Integrative pump device makes more smooth operation and easier installation and maintenance.
* Brand-new STM32 ARM-Cortex M3 platform, optimized circuit design, operation rate more fast and stable.
* Ample and user-friendly indicator information; accurate and complete alarm information to ensure safe injection.
* Unique wireless infusion supervision function, achieving accurate infusion and synchronization infusion supervision to patients.
Technical Parameters of MC-SP05IIIA Multi-channel Syringe Pump
Max. injection rate |
1500ml/h(Different injectors have different maximum rate.) |
Accumulated volume |
0.1ml~999.9ml |
Max. size of outer shell |
320 mm×200 mm×110 mm(length×width×height) |
Injection accuracy |
±3%( up to +1% after calibration.) |
Applicable injectors |
5cm, 10cm, 20cm, 30cm, 50ml |
Injection increment |
0.1ml/h |
Battery |
AC 100~240V,50/60Hz |
Volume limit |
0.1ml~999.9ml |
Batteryrecharge |
Rechargeable Lithium Polymer battery,7.4V,1600mA |
Classification |
ClassII, Type BF |
Max. power consumption |
Single-channel works for continuous 5 hours at the rate of 25ml/h after fully recharged; double-channels works for continuous 3 hours at the rate of 25ml/h after fully recharged. |
Range of flow rate |
5ml injector: 0.1ml/h~100ml/h 10ml injector:0.1ml/h~200ml/h 20ml injector:0.1ml/h~400ml/h 30ml injector:0.1ml/h~600ml/h 50ml injector:0.1ml/h~1500ml/h |
Bolus rate |
5mlinjector: 100ml/h 10mlinjector:200ml/h 20mlinjector:400ml/h 30ml injector:400~600ml/h(adjustable) 50ml injector:400~1500ml/h(adjustable) |
Alarm information |
Near completion, completion, OCCL., injector off, low voltage, No AC Power supply, communication error, link abnormal, pump stuck, reading error of the parameters, etc. |
Mode selection |
1. Rate mode 2. Time mode 3. Body Weight mode 4. Link mode |
Rate mode |
Rate:0.1ml/h~1500.0ml/h(Max. value depends on injector specification) |
Time mode |
Volume:0.1ml~999.9ml Time:1min.~2000 min. |
Body Weight mode |
Weight:0.1kg~300.0kg drug:0.1mg~999.9mg volume:0.1ml~999.9ml dose:0.1~1500.0(restricted to unit, drug, solution, weight and injector) Unit:mg/kg/h, ug/kg/min |
OCCL. value |
40Kpa~160Kpa,display the voltage status and the pressure value. |
KVO rate |
Adjustable range:0.1ml/h~5.0ml/h(adjustable: 0.1ml/h per each segment,press “0” to cancel KVO function.) |
