MeCan Medical Best Quality Shadowless led operating lamp Factory,MeCan provide one-stop solutions for new hospitals,clinics,labs and universities,has helped 270 hospitals,540 clinics,190 vet clinics to set up in Malaysia,Africa,Europe,etc.we can save your time,energy and money.
Quantity: |
---|
Type:Operation Illuminating Lamps
Place of Origin:CN;GUA
Instrument classification:Class II
Brand Name:MeCan
Model Number:MCL-LED500
MCL-LED500
1,Ideal cold light effects.
Using the new LED cold light source, energy saving and environmental protection and long service life up to 80,000hours or more. Temperature increase over surgeon’s head<1℃.
1)LED do not engender infrared ray and ultraviolet radiation, it doesn’t have the temperature rise and tissue damage caused by halogen shadowless light, can accelerate the wound healing after surgery, and has no Radiation pollution.
2)LED color temperature constant, soft, very close to the natural sun light.
2,Excellent shadowless effect
Lamp with the most scientific radian,Multi point light source design, so that more fullness of the light spot,When the lamps are partially occluded, also can achieve perfect shadowless effect.
1)Lamp panel radius of gyration: ≥182cm, the lamp can be pulled to vertical floor, convenient to any angle illumination.
3,Excellent deep lighting
4,Advanced control system
1)The liquid crystal display push-button control for power switch, illumination, color temperature adjustment, to meet the requirements of different medical staff and patients.
2)It offers illuminance memory function.
5,Universal suspension system
1)Rotating arm, a new type of alloy material is made of eight edge type.
2)Balance system adopts imported arm spring assembly,The structure is light, easy to manipulate, accurate positioning, can provide the maximum range of regulation.
3)The equipped with fatigue correcting unit and fix position hand handle device, easy to fix position after long time use.
6,Modern laminar lamp
1)The thickest part of lamp-chimney is not more than 10cm.
2)The lamp-chimney is made of Imported aluminum material, The handle on the central of lamp can be detachable, can take high temperature (≤ 134°C) sterilization treatment, easily adjust, flexible fixed.
Technical parameters | LED700 | LED500 |
40,000-180,000 | 30,000-160,000 | |
Lamp bulb quantity | 80 | 48 |
≥80000h | ≥80000h | |
Color temperature adjustable | 3700K~5000K | 3700K~5000K |
Color rendering index (CRI) | 85~98 | 85~98 |
Illumination depth(mm) | 50-180cm | 50-180cm |
Facular diameter(mm) | 160-280mm | 160-280mm |
Dimming Control | 1%-100% | 1%-100% |
Bulb Power | 80 | 48 |
Temp Rise (doctor head) | <1℃ | <1℃ |
Inputvoltage | AC100-240V 50/60HZ | AC100-240V 50/60HZ |
Best Install Height(m) | 2.7-3.1m | 2.7-3.1m |
