Main features
Colorful TFT screen with keyboard button
Automatic self-identification of 5mL, 10mL, 20mL, 30mL and 50mL syringes
Compatible with all kinds of syringe brands
4 injection modes: ml/h Mode. Weight Mode, Volume-Time Mode, Standby Mode
25 injection speed units
KVO & Bolus function
Visible and audible Alarms
Real time display
Rechargeable Lithium battery can work continuously for over 4.5 hours
Stackable combination with single AC power supply
Double CPU
Autosave 2000 syringe records
Technical Parameters
Applicable Syringe Specification |
5ml, 10m1, 20ml, 30ml, 50ml |
Syringe Brand |
Any syringe brand |
Scope of Injection rate |
0.1-100mI/h, 5mI Syringe |
0.1-600ml/h, 20ml Syringe |
|
0.1-800ml/h, 30ml Syringe |
|
0.1-1200ml/h, 50ml Syringe |
|
Bolus rate |
50-100ml/h(Default 50ml/h), 10ml Syringe |
50-300ml/h(Default 50ml/h), 10ml Syringe |
|
50-600ml/h(Default 50ml/h), 10ml Syringe |
|
50-800ml/h(Default 50ml/h), 10ml Syringe |
|
50-1200ml/h(Default 50ml/h), 10ml Syringe |
|
KVO rate |
0.1-1.0ml/h, adjustable at Increment level of 0.01ml/h |
Accuracy |
±2% |
Speed unit (Dose-rate unit) |
25kinds of injection-speed units as follows: ml/h, mg/min. m9/h, mg/24 mg/kg/min. mg/kg/h. mg/kg/24h. ug/min. ug/h, Ug/24h, ug/kg/min. ug/kg/h, ug/kg/24h, U/min, U/h, U/24h. U/kg/min, U/kg/h. U/kg/24h, kU/min, kU/h, kU/24h, kU/kg/min, kU/kg/h, kU/kg/24h |
Accumulated Injection Volume |
0.0001-999999ml |
VTBI |
0.1-1000ml |
Injection |
Three levels for selection: |
Pressure |
(L)300mm/Hg(M)500mm/Hg(H)1100mm/Hg |
Injection |
4modes: ml/h mode, Weight mode, |
Mode |
Volume-Time mode |
Alarm |
AC power failure, Syringe falls off, Reinstall syringe, Countdown, Air, Occlusion, Low battery, Error, Over, no enough drugs, beyond Parameters range |
Operating Condition |
Environment Temperature: 5℃-40℃ |
Power |
Relative Humidity: 20%-90% |
Atmospheric Pressure: 700 hPa-1060hPa |
|
AC 100V-240V, 50Hz/60Hz, |
|
DC 14.8V(+5%,-10%) 2000mAh rechargeable |
|
Input Power |
25VA |
Battery |
Rechargeable battery; Charging time: 12-16h; Discharge time: over 4.5h(when the battery is full) |
Fuse |
AC 250V 3.15A |
Safety Level |
Class 1, Type BF |
IP Grade |
IPX4 |
Dimension |
245mm x 135mm x 120mm |
Weight |
G.W:3.3kg, N.W: 2.3kg |
MeCan Medical is finely designed. Its design is finished by considering many factors such as frame construction, control system design, mechanism design, and operating temperatures.
