Color Doppler Ultrasound Machine compared with similar products on the market, it has incomparable outstanding advantages in terms of performance, quality, appearance, etc., and enjoys a good reputation in the market.MeCan Medical summarizes the defects of past products, and continuously improves them. The specifications of Color Doppler Ultrasound Machine can be customized according to your needs.
Availability: | |
---|---|
Model: MCI0512
1.Smart design
High Resolution Imaging System
Easy-operation Ergonomic Design
Better Optimize Image Quality
Smart and Light -Weight Design
2.Probes information
Probes | 5 Steps Multi-frequency |
3.5Mhz abdominal probe | 2.0, 3.0, 3.5, 4.0, 5.5Mhz |
7.5Mhz linear probe | 6.0, 6.5, 7.5, 10.0, 12.0Mhz |
6.5Mhz transvaginal probe | 5.0, 6.0, 6.5, 7.5, 9.0Mhz |
3.Technical specifications
Displaying mode | B,B/B,4B,B/M,M, B/C,B/C/D,B/D, duplex, triplex, CFM, PW |
Signal processing: | Full-digital beam forming, dynamic filter, dynamic real time receiving focusing, spectral processing, CFM processing, real-time dynamic focusing, dynamic aperture in all fields |
Image processing: | THI Storage: 16G Power adjustable Smoothing function Edge enhancement One-key optimization Image conversion Wall filter adjustable Base line adjustable PRF adjustable AIO-Auto image optimization IZoom: Instant full screen image I-Image: intelligent optimization MBF: Multi Beam Former SA: Synthetic Aperture Ultrasonic imaging Iclear: Speckle Noise Reduction CDF: Contunuous Dynamic Focusing |
General measurement | Normal, MSK, ABD, OB, Pelvic,Urology, Cardiac, Small Parts, Vascular |
Normal measurement | Volume, V3L, STD_S, Area Trace,Mtime, MHR, D Time, DV, D Common, D Auto, Area, Angle, CrossLine, STD D, ParalleLine, Mdist,MV, D HR, DA, D Trace |
ABD packages | ABD, Aorta, R_Kidney & L_Kidney, Bladder, Prostate |
OB Packages | Early_OB, Rt-Ovary, Lt-Ovary, Uterus, Fetal_Biome, Long_Bones, AFI |
Pelvic Packages | Uterus, Rt/Lt - Ovary, Rt/Lt-Follicle, |
Urology packages | Rt/Lt- kidney measurement, Bladder, Prostate,Rt/Lt_Testicle |
Small Parts | Rt/Lt_Thyroid, Rt/Lt_Testicle, Vessel, Breast |
Vascular | Stenosis D, senosis A, Intima, Arterial, Venous |
MSK | Distance, Area, Hip_Angle |
Scanning depth | ≥260mm |
Probe elements | 80 |
Gray | 256 |
Cine loop | Automatically & manually |
Image storage format | BMP, JPEG, PNG, DICOM(Option) |
Input/output ports | Video Port, S-Video Port, Remote Port, LAN1/2 Port, VGA |
Standard Configuration | Main unit, 12 inch LED monitor, 3.5Mhz convex probe, 7.5Mhz linear probe, 2 Probe connectors, User' s Manual, hard disk (SSD) |
Options | 6.5Mhz Transvaginal Probe, Trolley, Printers, Biopsy kit,Aluminum case |
Applicable Printers | HP Laser Jet P2035 |
HP Laser Jet 1022 | |
HP Laser Jet 1020 | |
SONY UP-D898MD | |
SONY UP-X898MD |
More detals of Color Doppler Ultrasound Machine
What is the delivery time?
A:We have shipping agent, we can deliver the products to you by express, air freight, sea. Below is some delivery time for your reference: Express: UPS, DHL, TNT, ect (door to door) United States(3 days),Ghana(7 days), Uganda(7-10 days), Kenya(7-10 days), Nigeria(3-9 days) Hand carry Send to your hotel, your friends, your forwarder,your sea port or your warehouse in China. Air freight(from airport to airport) Los Angeles(2-7 days), Accra(7-10 days), Kampala(3-5 days), Lagos(3-5 days), Asuncion(3-10 days)...
What is your payment term?
A:Our payment term is Telegraphic Transfer in advance, Western union, MoneyGram, Paypal, Trade Assurance,ect.
What is your after-sales service?
A:We provide technical support through operating manual and video, Once you have questions, you can get our engineer's prompt response by email,phone call, or training in factory. If it's hardware problem, within the warranty period, we will send you spare parts for free, or you send it back then we repair for you freely.
What is your warranty for the products?
A:More than 12 months for free
Quality Control (QC)
A:we have a professional quality control team to ensure that the final pass rate is 100%.
